Details
SKU
LY-36471
Categories
Brand
Product colour
Black
Harmonized System (HS) code
84733080
Cable type
Round cable
Quantity per pack
1 pc(s)
Cable length
1 m
HDMI version
2.0
Connector 1 gender
Male
Package type
Polybag
Maximum resolution
4096 x 2160 pixels
Colour depth
8 bit
Connector 2 gender
Male
Connector 1 form factor
Straight
Connector 2 form factor
Straight
Connector 2
HDMI Type A (Standard)
Cable jacket material
Polyvinyl chloride (PVC)
Connector contacts plating
Gold
Connector 1
HDMI Type A (Standard)
Certification
RoHS, REACH, UL
Connector material
Nickel
Connector housing material
Polyvinyl chloride (PVC)
Storage temperature (T-T)
-10 - 80 C
Data transfer rate
18 Gbit/s
AWG wire size
30
Cable material
Copper
Contact material
Phosphor bronze
Shield material
Aluminium
Supported graphics resolutions
4096 x 2160
Operating temperature (T-T)
-10 - 80 C
Colour sampling
4:4:4
Audio Return Channel (ARC)
Yes
HDMI Ethernet channel
Yes
Cable diameter
6 mm
Bending radius (min)
6 cm
Nominal attenuation
300kHz-825MHz 5dB, 825MHz-2.475GHz 5dB,2.475GHz-4.125GHz 12dB, 4.125GHz-5.1GHz 20dB
Connector 1 dimensions (WxDxH)
19.2 x 34.1 x 10.6 mm
Connector 2 dimensions (WxDxH)
19.2 x 34.1 x 10.6 mm
